Automatic tabletop ribbon film roll to roll slitting producing machine

Automatic tabletop ribbon film roll to roll slitting producing machine
Model:PK-C33S
Roll width : 330mm
maxl20mm Roll diameter: maxl20mm
Core diameter: 1”
Unwinding adjustment: Gear trimming
Roll diameter: 120mm
Core diameter: 1/2*' /1"
Rewinding mode: Biaxial synchronization
Max speed: lOOm/min cutting thickness: 4~20
slitting mode: blade
Speed mode: frequency control
Power:two-phase220/50~60HZ
Maximum power: Ikw
Air pressure : 0.6~0.8mpa
Machine size: 750*450*450mm

Automatic tabletop ribbon film roll to roll slitting producing machine

Model:PK-C33S

Roll width : 330mm

maxl20mm Roll diameter: maxl20mm

Core diameter: 1”

Unwinding adjustment: Gear trimming

Roll diameter: 120mm

Core diameter: 1/2*' /1"

Rewinding mode: Biaxial synchronization

Max speed: lOOm/min cutting thickness: 4~20

slitting mode: blade

Speed mode: frequency control

Power:two-phase220/50~60HZ

Maximum power: Ikw

Air pressure : 0.6~0.8mpa

Machine size: 750*450*450mm
