Automatic fruit vegetable weighing real time label print labeling machine

Automatic fruit vegetable weighing real time label print labeling machine

Weighing machine

Model:PK-W01

Weighing range: 5g-1500g

The highest detection accuracy: ±0.5 grams (the greater the weight, the faster the speed, the worse the accuracy, depending on the size, speed and weight of the product)

Minimum scale: 0.1g

Belt width: 220mm

Belt height from the ground: 800mm ± 50mm

Conveying speed: 20-60 m / min (frequency control)

Detection speed: 60~120 pieces/min

Conveying direction: facing the screen from left to right

Power supply: 220V 50-60HZ

External gas source: 0.6-1Mpa

Pneumatic interface: ￠ 8mm

Power: about 200W

Dimensions: about 1543mm (L) * 721mm (W) * 1470 ± 50mm (H)

Host weight: about 100Kg

Note:

1: The detection accuracy and speed are the experimental values ??of the standard state. The above parameters may be affected due to different working conditions, working environment and shape of the detected objects.

Printer machine

Model:GR-P01

(1) Width: 104mm

(2) Print length when printing head: 1651mm

(3) Resolution: 300dpi print head (12 points per mm)

(4) Memory: 4M SDRAM (user available 2MB), 2MB non-volatile flash memory (user available 750K)

(5) Label ribbon media material specifications

Label and liner width: 20 mm to 115 mm,

Label maximum roll size: paper roll outer diameter 203 mm inner diameter 76 mm

Label thickness: 0.076 mm to 0.305 mm

Label media type: continuous paper, die cut paper.

Labeling technical specifications:

Marking accuracy: ±1mm (not counting the sticker and label error)

Labeling speed: 0-15 / min

Air pressure: 5-6 kg

Power and power: 220V 50-60Hz;

Label: outer diameter up to 200mm

Label width: up to 100mm

Working temperature: 5-40 (°C)

Working humidity: 20-85%

1. Product use:

It is mainly used for weighing the products themselves on the automated assembly line, and prints labels containing real-time weight information and performs real-time labeling.

It can also replace manual weighing, printing, and labeling. This improves productivity and consistency and reliability in weighing, printing, and labeling.

Widely used in food, medicine, daily chemical, industrial manufacturing, printing, logistics and other industries.

2, automatic weighing sweep code section work process:

Before the weighing machine works, set the standard weight and overrun deviation of each box of objects (for example: standard weight 20g, lower deviation 2g, upper deviation 5g).

When the equipment is working normally, the object passes through the weighing machine, and the weighing machine weighs the actual weight of the object.

If the actual weight is less than 18g or greater than 25g. The weighing machine stops the alarm, waiting for the worker to handle the defective product, or has automatic rejection

The device automatically rejects non-conforming products without downtime.

If the object is within the standard weight range, the weighing machine sends a weight information to the print scan control industrial computer through the RS232 interface.

The industrial computer controls the automatic printing labeling machine to print the corresponding label according to the customer's preset printing template and automatically attach it to the measured box.

The barcode scanner will automatically read the barcode information and send it to the IPC for bar code data storage. (optional)

3. Features:

The large-size color touch screen interface is easy to operate and intuitive to display.

Reinforced stainless steel 304 frame, in compliance with GMP and HACCP regulations.

Simple mechanical structure for quick disassembly cleaning and maintenance.

200 product presets for easy switching.

Dynamic weight compensation technology ensures that weight data is more realistic and effective.

The labeling content can be arbitrarily set according to customer requirements.

The labeling position can be adjusted as needed according to the product specifications.

The labeling position is accurate and consistent.
